1.0m/1.2m Automatic satellite antenna NS-FM manufacturer from China Shaanxi Newstar Communications Equipment Co. Ltd

Price:	1.0~100000.0 USD
Payment Terms:	T/T,L/C,D/A,D/P,WU;Paypal
Place of Origin:	Shaanxi, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: NS-FM

Production Capacity: 10000

Delivery Date: Max 35 working days

Brand Name: Newstar

Means of Transport: Ocean,Land,Air

Packing: wooden boxes or according t...

Type: Outdoor

Frequency Range: c-band /ku-band

Conform with Intelsat, Eutelsat Requirements;
Carbon fiber reflector, high strength, light weight;
Good cross polarization, low sidelobe, high

1.0M automatic portable Antenna

Characteristics:

ü Antenna and communication equipments are designed according to the GJB63 Standards,adopting the "Three Proofings" measures and advanced modern production process, fitting to the field working environment;

ü Intelligent, miniaturization,and compact structure; modern design, small volume, light weight, vehicle or man carrying, convenient collection& transportation ;

ü At the same time,two operating mode for automatic and manual operation , agile and convenient;

ü Easy fast installation, 1 man 2.5 minutes independent to complete automatic capturing satellite;

ü Embedded receiver, control unit, GPS and control software system;

ü Higher tracking accuracy , of 1/10 receive beam width;

ü PDA wireless control, friendly man-machine interface,

ü Configuration agile, according to customer needs to provide different kinds of system configuration program for various network mode.

Accessories:

User manual,equipment integrated box;

Option:

LNB, BUC,Soft Waveguide,

Function:

◆One Touch automatic deploying,pointing star and collecting;

◆Available manual operation also;

◆Automatic positioning of latitude and longitude,tilt and roll angle ; pointing to star;

◆Automatic tracking, GPS and all kinds of sensor information, full service of accurate tracking data;

◆Unlimited the traffic conditions and the regional environment restriction, of complicated, emergency cases, implementation of fast, reliable and high quality audio/video and data communication.

PERFORMANCE SPECIFICATIONS

Type	NS-FA-100
Operating Frequency,GHz	Ku-Band
	Receive	Transmit
	10.75~12.75	13.75~14.5
Gain, Mid-Band, dBi	39.6	40.7
Polarization	Liner
XPD(on axis),dB -1dB	≥34 ≥29	≥34 ≥29
VSWR	1.3:1	1.3:1
-3dB Beamwidth, Mid-Band	1.6°	1.4°
Tx. Power Capability, KW		0.2kw/port
Feed interface	WR-75	WR-75
Feed Insertion Loss,dB	0.2	0.25
Isolation, Tx to Rx, dB	85	40
First Sidelobe 90%Peaks under Following envelop	-14dB 29-25 log θ dBi(1°≤θ＜20°)

MECHANICAL SPECIFICATIONS

Antenna Diameter		1.0 m
Antenna Type		Gregory
Weight(Net)		45 kg
Reflector	Dish Pieces	4 pics
	Antenna Form	offset elliptic paraboloid antenna
	Panel material	Carbon Fiber
Drive Range	Azimuth Travel	±90°
	Elevation Travel	10°to 90°
	Polarization Travel	±90°
Drive Speed	Azimuth Adj.(auto)	Low speed:0.3°/s;Quick speed:3.0°/s
	Elevation Adj.(auto)	Low speed:0.3°/s;Quick speed:3.0°/s
	Pol. Adjustment(auto)	5°/s
	Seeking	<5mins(antenna deploying-seeking end)
	Collecting	<5mins(one-touch collecting-collecting end)
power supply	AC	100-240 V, AC 50-400 Hz, 40W
power supply	DC	21-32 V DC,40 W
